Price: $89.99 | Compatible Model: Leica RX1250 Field Controller, ATX1230/GS10/GS14/GS15/GS16/GS18 GNSS Receiver, External Battery GEB70 / GEB171 / GEB373
This OEM Y-branch GEV215 integrated cable solves core RTK field connection troubles: separate power & data wires causing messy rover wiring, repeated plug switching between handset, GNSS receiver and external battery, loose aging original split cables, intermittent real-time RTK differential data transmission, voltage fluctuation triggering fixed solution dropout, and broken single-purpose wiring requiring two separate leads. Original triple Y design enables one cable to simultaneously connect controller, GNSS rover and large-capacity external battery without frequent plug replacement mid-survey.
|
 |
Product Overview
The Leica GEV215 all-in-one power-data Y cable with official OEM article number 756365A is a dedicated 2-meter triple-branch lead exclusively designed for Leica System 1200 & Viva GNSS RTK rover kits. Three bayonet-locked Lemo connectors layout: 1B 8Pin Male for RX1250 hand controller, another 1B 8Pin Male for GS series GNSS receiver port 1, 0B 5Pin Male for GEB series external high-capacity battery pack. Built with double-layer fully shielded pure copper wire core and wear-resistant anti-aging PUR outer sheath, it effectively isolates electromagnetic interference from construction machinery, vehicle engines and power lines, ensuring stable constant power supply and uninterrupted bidirectional RTK data transfer at the same time. Molded thick reinforced strain relief at every connector root prevents internal wire fracture from frequent plugging, pulling and vibration during all-day outdoor topographic and engineering stakeout work.
Core Advantages & Practical Structural Design
- Unique triple Y-branch layout: Dual Lemo 1B 8Pin Male + Single Lemo 0B 5Pin Male, one cable realizes handset data link + GNSS receiver connection + external battery power simultaneously
- Standard 2m extended total length, sufficient slack for handheld controller, tripod-mounted GNSS rover and ground-placed external battery without tangled tight wiring
- 100% replicated factory pinout definition, supports continuous long-hour external power supply, real-time RTK differential coordinate transmission, receiver parameter setup and offline firmware upgrade synchronously
- Dual independent shielding internal wiring, fully separates power circuit and data circuit to eliminate RF signal crosstalk and RTK fixed solution loss under external battery power input
- Flexible weatherproof PUR cable jacket, maintains soft intact performance under freezing winter and high-temperature summer construction site environments, anti-UV and anti-mud abrasion
- Twist bayonet locking Lemo connectors on all three branches, prevents accidental loose disconnection during field walking, instrument bumping and rover transportation vibration
- Wide compatibility: RX1250 wireless field controller, ATX1230, GS10/GS14/GS15/GS16/GS18 GNSS receivers, perfectly matched with GEB70, GEB171, GEB373 large-capacity external battery packs
- Compatible matching accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25, 0.2kg, 18 × 12 × 10 cm)
- Foldable compact Y-shape design, easy to roll and store in front accessory pouch alongside other single-branch serial wires, antenna coaxial cables and spare batteries
Synchronous RTK Data & Extended Power Field Application Scenarios
Mandatory multi-functional wiring accessory for large-area land boundary mapping, road & pipeline layout, construction stakeout, mine topographic survey and long-term building deformation monitoring RTK projects. Survey crews utilize GEV215 Y combo cable to power GS series GNSS rover via GEB373 external battery for 12+ hours continuous measurement, while maintaining stable real-time coordinate data link between RX1250 controller and receiver without stopping field work to swap separate power/data cables. Isolated power-data circuit design avoids sudden instrument shutdown or RTK signal interruption during simultaneous power supply and differential data transmission. Store this triple-branch Y cable and other tiny survey peripherals in our high-visibility yellow nylon data collector case; reinforced canvas belt loop supports waist hanging for convenient portable all-day field transport.
Product Specifications
| OEM Article Number | GEV215 / 756365A |
|---|---|
| Connector Layout | Y Triple Branch: Dual Lemo 1B 8Pin Male Bayonet Lock + Lemo 0B 5Pin Male |
| Standard Cable Length | 2 Meters |
| Outer Jacket Material | Weatherproof Wear-Resistant PUR Insulation |
| Matched Field Controller | Leica RX1250 Wireless Data Handset |
| Compatible GNSS Receivers | ATX1230, GS10, GS14, GS15, GS16, GS18 Viva / System 1200 Series |
| Matched External Batteries | GEB70, GEB171, GEB371 High Capacity External Battery Packs |
| Core Dual Function | Synchronous external power supply + bidirectional real-time RTK differential data transmission |
| Unit Net Weight | 0.20 kg |
| Stock Status | In Stock, Fast 24-Hour Global Dispatch |
| Matching Carry Case Specs | Yellow Wear-Resistant Nylon Case, Price $25, Weight 0.2kg, Dimension 18 × 12 × 10 cm |
Matching Survey Accessory: Trimble TSC3 / TSC2 Carrying Case ($25)
Constructed with thick tear-proof nylon fabric, this bright yellow field protective bag shields Trimble TSC2 & TSC3 handheld data collectors from scratches, dirt and minor impact damage. Equipped with solid canvas belt loop for waist mounting, the independent front storage compartment holds GEV215 Y-type power-data cables, other GEV series single-branch communication leads, GAD antenna arms and screen protectors. 20 units available in warehouse for immediate worldwide shipping.
Browse more Leica GNSS combined power-data Y cables, serial communication wires, external battery leads and RTK rover spare parts on xsurveying.com. We supply full series OEM-standard survey wiring accessories to realize synchronous long-duration external power supply and uninterrupted real-time RTK data links for efficient precision field measurement workflows.
