Price: $272.99 | Compatible Instruments: Leica FlexLine TS09 Touch, TS09plus Touch, TS06 Touch, TS07 Touch Entry Total Station; Matching Parts: TS09 Vertical Motion Wheel, TZ08 PN879743 Angle Encoder, GEB361 Lithium Battery, GKL311 Dual AC/Car Lithium Charger, TS09 Battery Door
This OEM-spec TS09 one-piece integrated front panel combines silicone numeric function keyboard + color TFT LCD + resistive touch digitizer + main control PCB board, solving complete front panel multi-faults of touch version FlexLine total stations: cracked touch glass, dead touch zones, blank/faded LCD screen, aging unresponsive silicone keys, damaged FPC cables, corroded main PCB circuit from rain/mud seepage, split separate screen & keyboard causing repeated disassembly maintenance cost, and mismatched third-party split components triggering system boot failure. 1:1 factory integrated assembly with unified FPC interface and IP54 sealing frame, one-step replacement to fully restore touch display + full numeric button dual operation for municipal pipeline control network, rural cadastral mapping, building layout stakeout and small open-pit mine high-precision survey projects.
Product Overview
The Leica TS09 dedicated all-in-one keyboard & touch screen front panel assembly is a complete integrated control module exclusively customized for FlexLine TS09 touch series total stations, interchangeable with TS06 Touch, TS07 Touch touch screen models. Full integrated layered structure: green front plastic housing frame + integrated silicone rubber full numeric shortcut keyboard mat (built-in metal dome switches) + 3.5-inch QVGA 320×240 industrial color TFT LCD + toughened resistive touch digitizer glass + uniform LED backlight module + integrated main control PCB board + dual gold-plated FPC flat ribbon signal cables + surrounding full-circle IP54 waterproof dustproof foam sealing gasket. Standard TS09 dedicated key layout includes red power key, 4-way navigation cross, ENTER/ESC, four yellow F1-F4 soft keys, FNC/USER programmable hotkeys, full 0-9 numeric keypad and measurement trigger quick key, perfectly matching FlexField Plus touch operation software logic. The touch digitizer supports glove operation for low-temperature winter construction sites; anti-glare LCD coating ensures clear data reading under direct midday sunlight. The integrated PCB adopts anti-corrosion immersion gold process, with independent short-circuit protection circuit to resist field vibration and damp tunnel environment erosion. Surrounding integrated sealing foam fits tightly with TS09 instrument front housing, retaining original IP54 dust & splash waterproof grade after overall replacement, blocking construction silt and rainwater from penetrating internal circuit to avoid mainboard burnout. Complete assembly with all internal wiring pre-connected, only two FPC plug-in interfaces during maintenance, eliminating separate disassembly of screen and keyboard to greatly shorten repair working hours.
Core Advantages & Practical Structural Design
- 100% OEM integrated overall dimension, FPC pin definition, key layout and touch screen resolution fully consistent with factory original TS09 touch front panel, one-piece plug-and-play maintenance replacement, no separate matching keyboard or touch screen spare parts
- Integrated dual operation system: physical silicone numeric shortcut keys + sensitive resistive touch screen, adapt to all field operation habits, support quick coordinate input and touch menu parameter configuration simultaneously
- High-elastic industrial silicone keyboard layer with independent metal dome switches under each key, anti-aging, anti-stick, clear press feedback, long service life without dead contact faults after 500,000 presses
- 3.5-inch QVGA anti-glare color TFT LCD with even low-power LED backlight, balanced brightness without dark edges, extend single-day field battery runtime compared to inferior split screens
- Toughened resistive touch glass, stable touch response without drift/dead zones, compatible with winter work gloves operation, solve single touch layer replacement frequent disassembly trouble
- Integrated immersion gold main control PCB with dual gold-plated FPC signal cables, anti-rust and anti-oxidation, eliminate intermittent screen flicker and touch lag caused by mud and humidity adhesion
- Integrated full-circle IP54 waterproof foam sealing frame, seamless fit TS09 instrument front housing, prevent liquid and fine dust penetrating internal PCB circuit to avoid short-circuit damage
- Universal cross-touch-model compatibility: FlexLine TS09 Touch, TS09plus Touch, TS06 Touch, TS07 Touch all entry touch total stations, matched with GEB361 high-capacity lithium batteries and GKL311 AC/car dual-use dedicated lithium charger
- Compatible matching accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25, 0.2kg, 18 × 12 × 10 cm)
- Integrated flat rectangular panel structure, complete shockproof foam independent packaging, easy classified storage in instrument maintenance tool cabinet alongside split touch screens, silicone keyboard single mats and mechanical repair small spare parts
TS09 Touch Total Station Overall Panel Maintenance & Field Survey Application Scenarios
High-efficiency integrated maintenance core spare part for rural cadastral boundary mapping, residential building construction layout stakeout, municipal pipeline control network measurement, small-scale open-pit mine topographic survey and simple foundation long-term settlement monitoring TS09 touch total station projects. When instrument simultaneously suffers touch screen crack, unresponsive physical keys, blank display or internal PCB corrosion faults, survey maintenance technicians directly replace this full integrated keyboard-touch screen assembly, instantly restore complete dual input operation and clear color data display without multiple times of split disassembly and matching spare parts, greatly reduce overall instrument maintenance cycle and labor cost. Anti-glare LCD and glove-supported touch layer adapt to open-air strong sunlight and low-temperature mountain winter construction environments; unified IP54 sealing structure effectively isolate rain and tunnel slurry erosion of internal circuit components to guarantee stable uninterrupted all-day high-precision survey measurement work. Store this TS09 integrated keyboard-touch screen assembly with shockproof foam packaging and other tiny survey maintenance peripherals in our high-visibility yellow nylon data collector case; reinforced canvas belt loop supports waist hanging for convenient cross-region field instrument repair transport.
Product Specifications
| Applicable Instrument Model | Leica FlexLine TS09 Touch, TS09plus Touch, TS06 Touch, TS07 Touch Total Station |
|---|---|
| Overall Integrated Structure | Front Housing Frame + Silicone Keyboard Mat + 3.5″ TFT LCD + Resistive Touch Digitizer + Integrated Main PCB + Dual FPC Cables + IP54 Sealing Foam |
| Screen Parameter | 3.5 Inch Color TFT, QVGA 320 × 240 Pixels, Anti-Glare Sunlight Readable Coating |
| Touch Type | Toughened Resistive Touch Glass, Support Glove Operation |
| Keyboard Internal Component | Full Layout Silicone Rubber + Independent Metal Dome Tactile Switches Per Key |
| Signal Transmission | Dual Gold-Plated Anti-Oxidation FPC Flexible Flat Ribbon Cables |
| Waterproof Matching Grade | Integrated Surrounding Foam Sealing Gasket, Match TS09 IP54 Dust & Splash Protection Standard |
| Matched Lithium Power Kit | GEB361 High-Capacity Li-ion Battery, GKL311 Dual AC/12V Car Lithium Charger |
| Mounting Method | Overall Front Panel Direct Replacement, Only Two FPC Plug-In Interfaces, No Split Component Matching Required |
| Core Function | OEM all-in-one integrated assembly to restore complete physical key + touch screen dual control & color data display for TS09 Touch series total station |
| Unit Net Weight | 0.142 kg |
| Stock Status | In Stock, Fast 24-Hour Global Dispatch, Independent Shockproof Foam Box Packaging |
| Matching Carry Case Specs | Yellow Wear-Resistant Nylon Case, Price $25, Weight 0.2kg, Dimension 18 × 12 × 10 cm |
Matching Survey Accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25)
Constructed with thick tear-proof nylon fabric, this bright yellow field protective bag shields Trimble TSC2 & TSC3 handheld data collectors from scratches, dirt and minor impact damage. Equipped with solid canvas belt loop for waist mounting, the independent front storage compartment holds TS09 integrated keyboard-touch screen assemblies, separate TS09 silicone key mats, standalone touch digitizer panels, vertical tangent motion wheels, TZ08 PN879743 angle encoders and touch screen protectors. 20 units available in warehouse for immediate worldwide shipping.
