Price: $112.99 | Compatible Model: Leica GAD34 3cm Antenna Arm, GEV120 TNC Coaxial Cable, Gainflex UHF/GSM Antenna, GS10, GS15, GS18 GNSS Receiver
This telescopic mounting rod solves typical RTK field setup issues: low antenna height causing signal occlusion, loose antenna bracket fixation, limited radio transmission distance, unstable vertical antenna support, and messy RF cable layout on construction sites. The adjustable multi-stage structure perfectly cooperates with GAD34 offset arm to lift antennas high up for clear, long-distance radio communication during all-day survey operations.
|
Product Overview
The LEICA GAD32 Telescopic Rod with OEM part number 667228 is a standard vertical support accessory designed for Leica GNSS rover and base station systems. Built with lightweight high-strength carbon fiber tubes covered by weather-resistant matte coating, it resists UV radiation, rain, dust and slight collisions in rugged outdoor survey environments. A universal 5/8-inch standard survey thread on the top end allows direct installation of GAD34 antenna arm without extra adapters, forming a complete factory-matched antenna mounting assembly.
Core Advantages & Structural Features
- Three-section retractable telescopic structure, freely adjustable working height for different site conditions
- Twist locking knobs provide firm fixation to avoid sliding during field vibration and movement
- Light carbon fiber material, greatly reduces carrying burden for field surveyors
- Top standard 5/8″ thread, perfectly matched with Leica GAD34 antenna extension arm
- Reasonable hollow wire routing design to organize GEV120 TNC coaxial cable neatly
- Compact folded size, convenient to store in survey backpack or equipment storage bag
- Stable vertical support, effectively lifts radio antennas to bypass trees, vehicles and building obstacles
- Compatible matching accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25, 0.2kg, 18 × 12 × 10 cm)
- Small folded segments can be placed in the front accessory pouch of the controller case together with small brackets and signal cables
Field Application & Signal Optimization
Widely used in GNSS RTK topographic mapping, construction layout, land boundary survey, engineering deformation monitoring and control network measurement projects. When paired with GAD34 antenna arm and GEV120 coaxial cable, GAD32 rod raises Gainflex UHF/GSM antennas to eliminate signal shielding obstacles, significantly improve radio receiving sensitivity and extend effective communication range. Match this telescopic rod with our yellow protective carrying case to store your data collector, antenna bracket, RF cable and other small survey accessories in one set; the reinforced belt loop supports waist hanging for convenient hands-free field transport.
Product Specifications
Matching Survey Accessory: Trimble TSC3 / TSC2 Carrying Case ($25)Made of thick wear-resistant nylon fabric, this high-visibility yellow case protects Trimble TSC2 and TSC3 data collectors from scratches, dust and minor impacts. Equipped with a sturdy canvas belt loop for waist mounting, the independent front storage pocket can hold GAD32 telescopic rod segments, GAD34 antenna arms, GEV120 coaxial cables, screen protectors and stylus tools. 20 units in stock for immediate global shipping.Check more Leica GNSS mounting brackets, RF signal cables and RTK survey spare parts at xsurveying.com. We supply full range OEM-standard survey accessories to ensure stable radio signals and efficient outdoor measurement work.
| OEM Part Number | 667228 (GAD32) |
|---|---|
| Material | Carbon Fiber Tube, Anti-corrosion Matte Coating |
| Telescopic Segments | 3 Sections |
| Top Mount Thread | 5/8 Inch Standard Survey Thread |
| Matching Accessories | GAD34 Antenna Arm, GEV120 TNC Coaxial Cable, Gainflex Radio Antenna, Leica GS Series GNSS Receiver |
| Unit Weight | 0.14kg |
| Stock Status | In Stock, Fast Dispatch Within 24 Hours |
| Matching Carry Case Parameters | Yellow Nylon Protective Case, Price $25, Weight 0.2kg, Size 18 × 12 × 10 cm |
