Price: $41.99 | Compatible Instruments: Leica FlexLine TZ05, TZ08, TZ12 Series Total Station; Matching Parts: GEB361 / GEB364 Lithium Battery, GKL311 Dual AC/Car Lithium Charger, TZ08 Touch Screen, TZ08 Angle Encoder PN879743
This OEM-spec TZ08 battery door assembly solves battery compartment common damage faults on TZ series total stations: original door shell cracked by field impact, aging rotary lock latch unable to lock lithium battery tightly, internal sealing foam falling off leading to IP66 waterproof failure, loose door causing battery poor contact & sudden instrument shutdown, generic non-OEM covers mismatched outline unable to fit machine housing, and damaged door allowing rain/tunnel slurry corroding battery contact shrapnel during long-hour outdoor measurement. 1:1 injection molded integrated housing + lock buckle + full-circle waterproof foam gasket assembly, perfectly seal and fix GEB36 series lithium battery to restore stable continuous power supply for tunnel deformation monitoring, high-speed railway control network and large infrastructure stakeout projects.
Product Overview
The Leica TZ08 dedicated battery door is a complete integrated compartment cover assembly exclusively customized for Leica FlexLine TZ05 / TZ08 / TZ12 survey total stations, fully interchangeable across the three TZ models. One-piece thickened PC-GF20 glass fiber reinforced green engineering plastic outer shell, built-in integrated rotary twist lock latch mechanism, surrounding full-circle closed-cell waterproof dustproof foam sealing ring, and embedded limit positioning ribs inside the door cavity. The shell adopts matte anti-UV coating, anti-drop and anti-brittle under -20℃ low temperature plateau environment, no permanent deformation after rock collision and backpack extrusion. The rotary lock buckle with built-in metal spring shrapnel provides stable clamping force, prevents battery pop-out during bumpy mountain transport and continuous automatic measurement vibration. Surrounding integrated sealing foam closely fits the instrument battery compartment frame, completely retain TZ08 original IP66 dust & splash protection grade after installation, block fine dust, rainwater and construction mud penetrating internal power contact components to avoid short-circuit burnout of mainboard circuit. Full assembly includes battery door main shell, rotary lock buckle, integrated waterproof foam gasket and positioning limit ribs, direct disassembly replacement without instrument internal circuit modification during maintenance repair.
Core Advantages & Practical Structural Design
- 100% OEM molded shell contour, lock latch structure, sealing frame size and internal limit rib layout fully consistent with factory original TZ08 battery door, direct bolt-free snap-on maintenance replacement for cracked, deformed or seal-failed original compartment cover
- Thick PC-GF20 glass fiber reinforced composite housing, ultra-high impact resistance, effectively resist field collision damage, solve the easy-cracking defect of ordinary pure plastic battery doors
- Ergonomic one-hand rotary twist lock buckle with built-in metal spring, smooth battery loading/unloading operation, constant clamping force to firmly lock GEB361/GEB364 lithium battery without shaking or loose contact
- Integrated full-circle closed-cell waterproof foam gasket, seamless fit with instrument battery compartment edge, maintain IP66 high protection standard to adapt rainy, muddy tunnel and open-pit mine harsh construction environments
- Internal multi-direction limit positioning ribs, restrict battery vertical and horizontal displacement, eliminate power intermittent dropout caused by battery shaking during all-day long-distance survey transfer
- Matte anti-UV outer surface treatment, long-term outdoor sunlight exposure will not fade, hard scratch-resistant coating easy to wipe mud and dust without leaving marks
- Universal cross-model compatibility: FlexLine TZ05, TZ08, TZ12 touch and manual version total stations, perfectly match GEB361/GEB364 high-capacity lithium batteries and GKL311 AC/12V car dual-use dedicated lithium charger
- Compatible matching accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25, 0.2kg, 18 × 12 × 10 cm)
- Curved compact integrated door assembly, lightweight thin structure easy storage in instrument maintenance tool pouch alongside TZ08 touch screens, angle encoders PN879743, silicone keyboard mats and mechanical repair spare parts
TZ08 High Precision Total Station Maintenance & Field Survey Application Scenarios
Necessary daily maintenance mechanical spare part for high-speed railway settlement long-term monitoring, urban tunnel ultra-precise control network layout, large bridge static observation, open-pit mine high-precision topographic mapping and rural cadastral high-accuracy boundary measurement TZ08 series total station projects. Survey maintenance technicians replace damaged original battery door with this full OEM integrated assembly, tightly lock GEB36 series lithium battery inside the compartment to realize stable uninterrupted high-current power supply, avoid frequent sudden instrument shutdown interrupting millimeter-level precision angle & distance measurement recording. Integrated IP66 full sealing foam effectively isolate rainwater and underground slurry erosion of battery contact terminals during rainy and tunnel field work; reinforced glass fiber shell completely solve door cracking, loose lock and waterproof failure faults to guarantee continuous reliable all-day survey operation. Store this TZ08 battery door assembly and other tiny survey maintenance peripherals in our high-visibility yellow nylon data collector case; reinforced canvas belt loop supports waist hanging for convenient cross-region field instrument repair transport.
Product Specifications
| Applicable Instrument Series | Leica FlexLine TZ05, TZ08, TZ12 Touch & Manual Total Station |
|---|---|
| Main Door Shell Material | PC-GF20 Glass Fiber Reinforced Matte Green Engineering Plastic, UV Anti-Aging Coating |
| Lock Mechanism | Integrated Rotary Twist Lock Buckle With Built-In Metal Spring Shrapnel |
| Waterproof Dustproof Component | Surrounding Integrated Closed-Cell Foam Sealing Gasket, Match TZ08 IP66 Protection Grade |
| Internal Structure | Multi-Directional Positioning Limit Ribs For Battery Anti-Shake Fixing |
| Matched Lithium Power Kit | GEB361, GEB364 High-Capacity Li-ion Battery, GKL311 Dual AC/12V Car Lithium Charger |
| Mounting Method | Snap-On Direct Replacement, No Extra Fixing Screws Required |
| Operating Temperature Range | -20℃ ~ +55℃, Low Temperature Anti-Brittle Shell Performance |
| Core Function | OEM complete battery compartment door assembly to lock lithium battery tightly & maintain IP66 waterproof sealing for TZ08 series total station stable power supply |
| Unit Net Weight | 0.068 kg |
| Stock Status | In Stock, Fast 24-Hour Global Dispatch |
| Matching Carry Case Specs | Yellow Wear-Resistant Nylon Case, Price $25, Weight 0.2kg, Dimension 18 × 12 × 10 cm |
Matching Survey Accessory: Trimble TSC3 / TSC2 Yellow Nylon Carrying Case ($25)
Constructed with thick tear-proof nylon fabric, this bright yellow field protective bag shields Trimble TSC2 & TSC3 handheld data collectors from scratches, dirt and minor impact damage. Equipped with solid canvas belt loop for waist mounting, the independent front storage compartment holds TZ08 battery door assemblies, PN879743 angle encoders, TZ08 touch screen panels, silicone keyboard mats and touch screen protectors. 20 units available in warehouse for immediate worldwide shipping.
