Leica TS06 Communication Side Cover (Bluetooth Side Cover)
Our Leica TS06 Bluetooth communication side cover replacement costs $85–$198, fully compatible with Leica FlexLine TS02 / TS06 / TS09 total stations. This OEM-grade side cover fits perfect for repairing broken Bluetooth modules, damaged USB ports and cracked instrument side housings on field survey total stations.
Core Technical Specifications
- Core Interfaces: Integrated Bluetooth antenna, USB Host port, Mini USB (USB Device) port and internal flat cable connectors for mainboard connection.
- Assembly Specifications: Fastened with 4 screws (Model: M2.5×10, torque: 40 Ncm). A brand-new sealing gasket must be installed during reassembly to maintain the instrument’s IP55 rating.
- Internal Components: Equipped with a dedicated USB/Bluetooth host board, which connects to the mainboard, tilt sensor and vertical slip ring via flat cables.
|
Official Part Numbers
| Component Description | Leica Original Part Number | Remarks |
|---|---|---|
| Complete communication side cover (with USB/Bluetooth mainboard) | 760467 | Standard assembly for TS06/TS06plus, TS02, TS09 |
| Empty side cover shell (no circuit board) | 760847 | Spare shell without electronic modules (released as an additional spare part) |
| Bluetooth antenna assembly | 762796 | Matching accessory for the communication side cover |
| Sealing gasket for side cover | 781388 | Waterproof & dustproof rubber ring |
Product Type
It is a combined structural & communication assembly for Leica FlexLine TS06 total station, categorized into two types for maintenance and replacement:
- Full assembly: Outer shell + sealing gasket + USB/Bluetooth circuit board + built-in antenna (factory standard configuration).
- Separate spare parts: Independent outer shell, circuit board, antenna and sealing ring (for repair and component replacement).
Material Composition
- Main Shell: PC-GF20 glass fiber reinforced engineering plastic (impact-resistant, low-temperature resistant, insulating, suitable for harsh field survey environments).
- Sealing Parts: High-performance rubber gaskets (ensures IP55 dustproof and waterproof performance).
- Internal Module: Standard PCB (Printed Circuit Board) with Bluetooth and USB electronic components.
- Antenna: Flexible built-in Bluetooth antenna.
- Fasteners: Galvanized carbon steel screws (anti-rust treatment).
Functional Introduction
Main Functions
- Bluetooth Wireless Communication
Supports wireless connection with Leica CS10, CS15 and other field controllers. It realizes wireless data transmission and remote instrument operation, eliminating the limitation of data cables and improving the efficiency of stakeout and topographic survey in field operations.
- Dual USB Data Interaction
- USB Host Port: Compatible with industrial USB flash drives (e.g. Leica MS1 1GB). It supports on-site data storage, viewing and file export, and is compatible with GSI, DXF, LandXML, CSV and other mainstream survey data formats.
- Mini USB (USB Device) Port: Connects to a PC, charger or external device via dedicated data cables for firmware upgrade, batch data transmission and power supply.
- Structural & Protective Function
Seals the instrument’s side interface and internal circuits. Cooperates with the rubber gasket to block dust and water, protecting precision electronic components. It adapts to the standard operating temperature range of -20°C to +50°C (Arctic version supports -35°C) and meets IP55 protection standard.
- Internal Wiring Carrier
Fixes internal flat cables and Bluetooth antennas, standardizes the wiring layout, and guarantees stable signal transmission of tilt sensors and angle measurement modules.
Environmental Resistance & Protection Grade
- Ingress Protection: IP55 (Dust-proof and low-pressure water jet resistant)
- Standard Operating Temperature: -20 °C ~ +50 °C
- Arctic Version Operating Temperature: -35 °C ~ +50 °C (for extreme cold regions)
- Storage Temperature: -40 °C ~ +80 °C
- Humidity Resistance: Up to 95% non-condensing humidity
Compatible Models
Leica FlexLine TS06, TS06plus, TS02, TS09 series total stations.
Maintenance & Operation Notes
- All disassembly and assembly work must be performed in a static-free (ESD) and dust-free environment to prevent static damage to the Bluetooth/USB circuit board.
- After replacing the USB/Bluetooth host board, the instrument firmware must be updated to V2.34 or above to ensure normal use of communication functions.
- All fixing screws must be tightened at a torque of 40 Ncm to avoid thread slipping or sealing failure.
- The old sealing gasket is prohibited from being reused after disassembly; a new gasket must be installed.
